| Size | 00B/0B/1B/2B/3B |
|---|---|
| Keying | 1 Key Fixing |
| Endurance (Shell) | 5000 Mating Cycles |
| Shell Style | PHG Free Socket |
| IP Rating | IP50 |
| Insulator | P:PPS |
|---|---|
| Contact Type | Solder/printed Circuit |
| Endurance (Shell) | 5000 Mating Cycles |
| IP Rating | 50 |
| Specifications | Low Voltage |
| Size | 1B |
|---|---|
| Type | Adapter |
| Color | Silver |
| Pin | 2-12pin |
| Connector Type | Male Terminals |
| Size | 1B |
|---|---|
| Insulator | P:PPS |
| Contact Type | Solder |
| Configuration | Brass (gold Plated) |
| Pin | Right Angle |
| Pin No | 2-32pin/Multi Pin |
|---|---|
| Max. Matings | 5000 |
| Temp (min) | -20 Deg C |
| Temp (max) | +150 Deg C |
| Style | Push Pull Self-locking |
| Locking Style | Push Pull Self-locking |
|---|---|
| Endurance (Shell) | 5000 Mating Cycles |
| Contact Type | PCB Welding |
| Rated Current | 10 Amps |
| Shock Resistance | 100g.6ms |
| Size | 1B |
|---|---|
| Insert | 1B.302 : 2 Low Voltage |
| Max. Matings | 5000 |
| Salt Spray Corossion Test | > 48hrs |
| Shock Resistance | 100g.6ms |
| Housing Material | Brass Chrome Plated |
|---|---|
| Insulator | P:PPS |
| Pin No | 2-32pin/Multi Pin |
| Shell Style | FHG Right Angle |
| Contact Type | Cable Solder |
| Size | 0B 1B 2B |
|---|---|
| Pin | 6pin |
| Specifications | Low Voltage |
| Configuration | Brass (gold Plated) |
| Housing Material | Brass Chrome Plated |
| Size | 00B |
|---|---|
| Series | FGG*: Straight Plug/ EGG* Female Socket |
| Keying | G |
| Housing Material | Brass Chrome Plated |
| Configuration | Brass (gold Plated) |
