Tentacle Right Angle 3.5mm TRS To Straight Audio BNC Timecode Cable HIFI Assembly
Product Description
Tentacle right angle 3.5mm TRS to straight Audio BNC Timecode Cable HIFI Assembly
Features:
BNC CONNECTOR SERIES:
The BNC is a bayonet style connector allowing for quick connect and disconnect with a positive locking mechanism.
Mating is achieved with just a quarter turn of the coupling nut.
With a classic, dependable design, BNCs are suited to accommodate a large variety of RG and industry standard cables, in a variety of termination styles.
Ebuddy offers a full line of BNCs in a multitude of options. From 50 Ω to 75 Ω Impedance, Commercial to grade, BNC connectors are miniature, lightweight and reliable.
A full line of printed circuit board receptacles, bulkhead receptacles, reverse-polarity connectors, resistor terminations, and other accessories complement the product offering.
Specification:
BNC Connector Technical Datasheet
Electrical Characteristics
Impedance
50 ohm or 75 ohm
Frequency Range
0-4 GHz
VSWR
(Voltage Standing Wave Ratio)
Straight type ≤ 1.22/3GHz,
R/A type ≤ 1.30/3GHz
Dielectric Withstanding Voltage
1500 V rms
Working Voltage
500 V rms
Center Contact Resistance
≤ 1.5 mΩ (Milliohms max.)
Outer Contact Resistance
≤ 2.0 mΩ (Milliohms max.)
Insultation Resistance
≥5 × 10³ mΩ (Milliohms min.)
Mechanical Characteristics
Coupling
Bayonet
Contact Retention
6 lbs min
Mating Durability
≥500 cycles
Environmental Characteristics
Temperature Range
Teflon -55℃~+155℃ / POM -40℃~+60℃
Coupling Nut Retention
100 lbs. min
Vibration
MIL-STD-202 Meth. 204
Corrosion Resistance
MIL-STD-202 Meth. 101
Application:
Audio & video,
Aviation,
Communications,
Industrial Control,
Information Systems Machines.
Our Service:
To Be Your The Best Connection Expert:
1)Low cost but good quality in ip67 waterproof in locked condition with ISO9001 management under efficient service.
2) Provide free samples within 3 working days if it is normal product with existing tooling.
3) Effective communication and rapid response .
4) Early design-in capability,OEM, ODM are available .
5) Globalization, localization of operation and management .
